High Energy Nd:YAG Laser Mirrors D=12.7mm 45° 355nm
Price Option
Please Consult
Product No. 453001
Stock Please Consult
Express DHL, Fedex etc.
Product file downloadClick file to download
- Dia Φ12.7mm
- Thickness 6.35 mm
- Coating HR@355nm
- Reflectivity Rs=99.5%;Rp＞99%
- Angle of Incidence 45°
- Material Corning 7980
- Irregularity(P-V) λ/10
- Damage Threshold 10J/cm² (355 nm,10ns,10Hz)
- Clear Aperture ＞95%
- Surface Quality 20-10
- Diameter Tolerance 0/-0.1mm
- Thickness Tolerance ±0.1mm
- Bevel Protective Bevel
Grand Unified Optics provide laser mirrors with high quality fused silica substrate and total dielectric high reflection, the reflection is very high within the fixed laser wavelength. The fused silica substrate reduces the dispersion of the light effectively. AOI for thse laser mirrors is 0° and 45° depending on your application.
