Prism Mounts
The Prism Mount is suitable for installing optical components such as prisms and cubes. With a mounting plate, an adjustable pressure arm can be installed with a maximum height of 50.8mm optical components, two M6 x 0.25 adjustment screws achieve ±4 ° pitch and tilt adjustment, 0.4 ° / turn adjustment accuracy. The rear panel has 2 M4 countersunk holes. There are 5 M4 threaded through holes on the mounting plate for mounting the pressure arm. The end of the pressure arm has a nylon head fixing screw (compatible with a 2 mm hexagon wrench) to press the optical element on the mounting plate.
Product characteristics
1. Two Adjusters for ±4° of Fine Tip and Tilt Control
2. Platform can be Moved to Either Arm for Left- or Right-Handed Configuration
3. Designed for Use with Clamping Arms
4. Provide kinematic control for prisms, cube beamsplitters, corner cubes, and other optics that require tip and tilt control
5. Fabricated from Black Anodized Aluminum
Product characteristics
1. Two Adjusters for ±4° of Fine Tip and Tilt Control
2. Platform can be Moved to Either Arm for Left- or Right-Handed Configuration
3. Designed for Use with Clamping Arms
4. Provide kinematic control for prisms, cube beamsplitters, corner cubes, and other optics that require tip and tilt control
5. Fabricated from Black Anodized Aluminum
