Motorized Nano Microscope Translation Stage Travel=75×75mm
Price Option
Product No. 527000
Stock Please Consult
Express DHL, Fedex etc.
Product file downloadClick file to download
- Travel 75×75mm
- Motor Drive M304
- Max Speed 20mm/s
- Axial Thrust 16N
- Max Load 2kg
- Min Step 50nm
- Repositioning Accuracy 0.3μm
- Position Sensor grating ruler
- Body Maerial Aluminium Alloy, with Anodizing Treatment
- Geometry Dimension 200×200×42mm
- Weight（kg) 3.49
Piezoelectric motor drive
With power-off self-locking, brake function and no return backlash
Minimum stepping 50nm
Can choose magnetic grating ruler or grating ruler as position feedback sensor
Ultra-thin compact design, Height only 26 mm
Suitable for used as a loading platform for various microscopes and test equipment
