16mm 4/3" 10M Fixed Focal Length Lens
Price Option
Product No. 600017
Stock In Stock
Express DHL, Fedex etc.
Product file downloadClick file to download
- Focal Length 16mm
- F/# 2
- Max. sensor size 4/3"
- Mount C
- Resolution 10MP
- Working Distance 0.1m～∞
- Filter Thread M58.0×0.75mm
- FOV 72.9°×60.9°×47.3°
- Distrotion -2.81%@y=11.5mm
- Weight 338g
| No. | Item | Specifications | |
| 1 | Max. sensor size | 4/3"(23mm） | |
| 2 | Focal Length | 16mm | |
| 3 | Mount | C-Mount | |
| 4 | F/# | F2.0-F22 | |
| 5 | Working Distance | 0.1m～∞ | |
| 6 | FOV(Diagonal x H xV) | 4/3" | 72.9°×60.9°×47.3° |
| 1" | 54.0°×44.2°×33.6° | ||
| 1/2" | 28.2°×22.70°×17.1° | ||
| 1/3" | 21.3°×17.1°×12.8° | ||
| 7 | Object Size (at the minimum focus distance) |
4/3" | 195.5×145.5×107.3mm |
| 1" | 125.4×99.2×73.8mm | ||
| 1/2" | 61.2×48.8×36.5mm | ||
| 1/3" | 45.7×36.5×27.4mm | ||
| 8 | BFL（in air） | 21.00mm | |
| 9 | Operation | Focus | Manual |
| Aperture | Manual | ||
| 10 | Distortion | 4/3" | -2.81%@y=11.5mm |
| 1" | -1.92%@y=8.0mm | ||
| 1/2" | -0.59%@y=4.0mm | ||
| 1/3" | -0.34%@y=3.0mm | ||
| 11 | Filter thread | M58.0×0.75mm | |
| 12 | Lens Size(W x L) | 60×89.89mm | |
| 13 | Weight | 338g | |
| 14 | Work Temperature | -10℃～+50℃ | |
| 15 | Distance of entrance pupil | 23.83mm | |
| 16 | Diameter of entrance pupil | 8.01mm | |
| 17 | Distance of exit pupil | -67.17mm | |
| 18 | Diameter of exit pupil | 34.78mm | |
| 19 | Total optical length | 99.94mm | |
| 20 | Magnification | -0.132 | |
| Focus Distance | Magnification | Front DOV(mm) | Back DOV(mm) |
| 100mm | -0.13198 | 0.5709 | 0.5775 |
| 150mm | -0.09333 | 1.2810 | 1.3032 |
| 200mm | -0.07224 | 2.2708 | 2.3236 |
| 250mm | -0.05892 | 3.5381 | 3.6411 |
| 300mm | -0.04973 | 5.0805 | 5.2586 |
| 350mm | -0.04307 | 6.8956 | 7.1784 |
| 400mm | -0.03796 | 8.9812 | 9.4035 |
| 450mm | -0.03393 | 11.3350 | 11.9364 |
| 500mm | -0.03068 | 13.9548 | 14.7798 |
| 550mm | -0.02800 | 16.8383 | 17.9366 |
GA 4/3" 10M FA lens is specially designed for 4/3" imaging sensors. Standard c-mount design, can matching most of c-mount cameras; The maximum focal length up to 85mm, imaging diameter reach to 23mm, it has great advantages for large imaging applications.
Product characteristics
1. 10 Mega pixels, 4/3" imaging Format，150lp/mm@±8.8mm，100lp/mm@±11.5mm;
2. Full focal length covers 8-85 mm;
3. Max image diameter up to23mm, compatible area Camera and Line scan camera;
4. Standard C-mount design, matching C-mount industrial cameras.
